Protection Features: |
Overload/Short Circuit/Overvoltage/Overtemperature |
Backup Power: |
Yes |
Battery Type: |
Lead-acid/Lithium |
Solar Charge Controller: |
MPPT |
Maximum Output Power: |
5000W |
Grid Tie Function: |
No |
Inverter Type: |
Hybrid |
Communication Interface: |
RS485/Wi-Fi |
Lcd Display: |
Yes |
Protection Features: |
Overload/Short Circuit/Overvoltage/Overtemperature |
Backup Power: |
Yes |
Battery Type: |
Lead-acid/Lithium |
Solar Charge Controller: |
MPPT |
Maximum Output Power: |
5000W |
Grid Tie Function: |
No |
Inverter Type: |
Hybrid |
Communication Interface: |
RS485/Wi-Fi |
Lcd Display: |
Yes |
| Inverter Data | ||
| MODEL | 3500HHS-24 | 5500HHP-48 |
| CAPACITY | 3.5KVA/3.5KW | 5.5KVA/5.5KW |
| Parallel Capability | NO | Yes,12pcs |
| INPUT | ||
| Nominal Voltage | 230VAC | |
| Acceptable Voltage Range | 170-280VAC(For personal Computer);90-280VAC(For Home Appliances) | |
| Frequency | 50/60 Hz(Auto sensing) | |
| OUTPUT | ||
| Nominal Voltage | 220/230VAC±5% | |
| Surge Power | 7000VA | 11000VA |
| Frequency | 50/60 Hz | |
| Waveform | Pure sine wave | |
| Transfer Time | 10ms(For personal Computer):20ms(For Home Appliances) | |
| Peak Efficiency (PV to INV) | 96% | |
| Peak Efficiency (Battery to INV) | 93% | |
| Overload Protection | 5s@>=150%load; 10s@110%~150%load | |
| Crest Factor | 3:1 | |
| Admissible Power Factor | 0.6~1(inductive or capacitive) | |
| BATTERY | ||
| Battery Voltage | 24VDC | 48VDC |
| Floating Charge Voltage | 27VDC | 54VDC |
| OverCharge Protection | 33VDC | 63VDC |
| Charging Method | CC/CV | |
| SOLAR CHARGER & AC CHARGER | ||
| Solar Charger TYPE | MPPT | |
| Max.PV Array Power | 4000W | 5500W |
| Max.PV Array Open Circuit Voltage | 500VDC | |
| PV Array MPPT Voltage Range | 120VDC-450VDC | |
| Max.Solar Input Current | 15A | 18A |
| Max.Solar Charge Current | 100A | 100A |
| Max.AC Charge Current | 60A | 60A |
| Max.Charge Current(PV+AC) | 100A | 100A |
| PHYSICAL | ||
| Dimensions,D*W*H(mm) | 482*290*113 | |
| Package Dimensions,D*W*H(mm) | 565*380*190 | |
| Net Weight(Kgs) | 9 | 10 |
| Communication Interface | USB/RS232/Dry-contact | |
| ENVIRONMENT | ||
| Operating Temperature Range | (-10°C to 50℃) | |
| Storage temperature | (-15°C to 60℃) | |
| Humidity | 5%to 95%Relative Humidity(Non-condensing) | |
