Product Details
Place of Origin: China
Brand Name: 1stess
Certification: CE, TUV Mark
Model Number: 540K2-200-200
Payment & Shipping Terms
Minimum Order Quantity: 1 piece
Price: negotiable
Packaging Details: container
Delivery Time: 45-60 days
Payment Terms: L/C, T/T
Supply Ability: 10 containers per month
Type: |
Electric Vehicle Charging Station |
Certifications: |
CE, TUV Mark |
IP Protection: |
IP55 |
Model: |
Ev Charging Station |
Monitor: |
OCPP 1.6J Update To 2.0 |
Safety Features: |
Overvoltage Protection, Overcurrent Protection, Leakage Protection |
Display: |
LCD Screen |
Output DC Voltage: |
150V-1000V |
Type: |
Electric Vehicle Charging Station |
Certifications: |
CE, TUV Mark |
IP Protection: |
IP55 |
Model: |
Ev Charging Station |
Monitor: |
OCPP 1.6J Update To 2.0 |
Safety Features: |
Overvoltage Protection, Overcurrent Protection, Leakage Protection |
Display: |
LCD Screen |
Output DC Voltage: |
150V-1000V |
The BESS Charging Station is compatible with CHAdeMO, CCS1/2 charging standards, which enables it to charge a wide range of electric vehicles. This charging station provides an output DC voltage of 150V-1000V, making it one of the most versatile chargers in the market. Whether you own a small electric car or a heavy-duty electric truck, the BESS Charging Station can provide fast and efficient charging.
The BESS Charging Station is a reliable and efficient charging solution that can help reduce your carbon footprint and save you money on fuel costs. By using renewable energy sources, such as solar or wind power, you can charge your electric vehicle without relying on non-renewable fossil fuels. This makes the BESS Charging Station an eco-friendly and sustainable choice for electric vehicle owners.
The BESS Charging Station is easy to install and comes with a user-friendly interface that allows you to monitor and control your charging sessions. You can set charging schedules, monitor charging status, and receive alerts on your mobile device, making it convenient and hassle-free to charge your electric vehicle.
In summary, the BESS Electric Vehicle Charging Station is a reliable and efficient charging solution that provides advanced safety features, compatibility with multiple charging standards, and a wide output DC voltage range. This renewable energy vehicle charger is an eco-friendly and sustainable choice for electric vehicle owners who want to reduce their carbon footprint and save money on fuel costs. With its user-friendly interface and easy installation, the BESS Charging Station is the perfect choice for your electric vehicle charging needs.
Introducing the BESS Vehicle Charging Hub, the ultimate solution for an eco-friendly and reliable charging experience. Our Renewable Energy Vehicle Charger is equipped with the latest technology and features to ensure maximum efficiency and convenience. The Battery Energy Storage System EV Charging Station is CE and TUV Mark certified, guaranteeing safety and quality.
| IHS540K2 540kW POWER CUBE | ||||
| AC grid access | AC input voltage | 45-65Hz/3-phases+N+PE/380/480Vac(±10%) | ||
| AC max input power | 360kW | |||
| AC Distribution | AC Grid charging power to Energy Storage Battery is max 120kW, Max. 240kW to EV | |||
| Max AC feedback power (optional) | EES Battery to Grid/EV battery to Grid, depend on the configuration of bidirectional AC2DC | |||
| Energy Storage Battery access | Battery group access | Max 2 groups | ||
| Battery capacity / group | 200kWh /280Ah /627V-806V/0.5 C dis/charge /max 0.75 C discharge 30 min | |||
| Battery charging power from AC Grid | Max 2* 60kW =120kW (4 ACDC power module configuration) | |||
| Battery discharging channel to EV | Max 4 channels | |||
| Battery B2V EV charging power | Max 4* 60kW =240kW (8 DCDC power module configuration) | |||
| Battery to Grid/ B2G feedback power (optional) | Depend on the configuration of bidirectional converter | |||
| Electric Vehicle charging | EV Charging point | Max 4 point with 2 Dispensers | ||
| EV Charging power | Max 360kW | |||
| EV Charging power transfer | Ring net power transfer between the 4 charging point | |||
| EV Charging voltage | 150V-1000V | |||
| Electric Vehicle discharging | EV feedback to AC Grid/V2G power (optional) | Depend on the configuration of the bidirectional AC2DC | ||
| Pv access | Access channel | Max 2 channel | ||
| Access power | Max 2*30kW MPPT | |||
| Metering | AC Grid side | 1 AC energy meter | ||
| HMI | 7"TFT Touch Screen, 5 LED, E-STOP | |||
| Dimensions | W*H*D mm = 1000 * 2200* 1150 mm | Weight: 550+21*18 = 928 kg (Full power modules) | ||
| Off Grid/Backup | Optional function, support backup power for AC bus / Backup power depend on the configuration of the bidirectional AC2DC | |||
Electric Car Battery Charger, Renewable Energy Vehicle Charger, BESS Sustainable Charging Solution
The 1stess Ev Charging Station is equipped with advanced safety features such as Overvoltage Protection, Overcurrent Protection, and Leakage Protection, ensuring the safety of both the user and the vehicle. The product is also certified by CE and TUV Mark, meeting the highest quality standards.
With an input voltage of AC 380V/480V, the 540K2-200-200 model of the 1stess Ev Charging Station supports CHAdeMO, CCS1/2 charging standards, making it compatible with a wide range of electric vehicles. This means that the BESS Vehicle Charging Hub can be used in a variety of scenarios, from public charging stations to private garages and car parks.
The 1stess Ev Charging Station is ideal for businesses and organizations looking to provide reliable and efficient EV charging solutions to their customers and employees. It is also suitable for residential use, providing a convenient and cost-effective way to charge electric vehicles at home.
Whether you're a business owner, a property manager, or a homeowner, the 1stess BESS Vehicle Charging Hub is an excellent choice for your EV charging needs. It offers a safe, reliable, and efficient charging solution, backed by industry-leading certifications and quality standards.
